Датчик LEM, LA205-S
Accuracy ±0.8 %
Frequency Bandwidth DC → 100 kHz
Input Current Range 0 → 300 A
Maximum Cable Diameter 22.7 x 17.4mm
Maximum Operating Temperature +85°C
Minimum Operating Temperature -10°C
Mounting Type Panel
Output Current Range 100mArms
Overall Depth 56.5mm
Overall Height 56.3mm
Overall Width 66mm
Sensor Type Closed Loop Hall Effect
Supply Voltage 12 → 15 V |
